Robust, agile and lightweight, the crosstrail sl combines the best of mavic's technologies, making it your best ally to tackle any trail.

Increased robustness

• The 30mm aluminium rim with FORE & PFP technologies make the Crosstrail SL an indestructible trail wheel

More responsive and dynamic

• The reduced inertia of the rim combined with INFINITY hub technology means instant acceleration

Ultra Versatile

• ISM4D rim lightening and spoking technology make the Crosstrail SL one of the most versatile trail wheels in its class

Weight

• Pair: 1980g
• Rear: 1092
• Front: 888

Understanding the different Mavic freehub body acronyms:

• HG or M11 - Shimano HG Road 11/12x (other speeds with spacer)
• MS - Shimano Microspline
• XD - SRAM XD
• XD-R - SRAM XD-R
• ED11 - Campagnolo 9/12x
• N3W - Campagnolo 13x

  ---

ADDITIONAL INFORMATION

Maxtal aluminium alloy

Light and strong. Exclusive to Mavic, this specific aluminium alloy offers a higher strength to weight ratio than the conventional 6106 alloy.

ISM 4D Light Rim Technology

Inter Spoke Milling 4 Dimensions (ISM 4D) is an exclusive Mavic patented concept. The ISM 4D significantly reduces weight and inertia without compromising durability. Quicker accelerations, better handling; the right mix to make the most of any ride. The smooth profile also helps reduce aerodynamic drag.

Fore Tapeless Tubeless Technology

Stiffer and Stronger. Instead of being drilled, the lower rim bridge is pushed up on the inside, then threaded to enable the spoke nipples to be directly screwed into it, leaving the upper rim bridge intact.

Instant Drive 360 technology

Super light and efficient. The large contactless rubber seal provides low friction, while a wide array of end caps makes it super versatile.

UST tubeless technology

Traction and control. Universal Standard for Tubeless. Ready to ride tubeless system. The UST concept improves traction, control and comfort whilst reducing inertia and flats.

SUP Welding technology

Soude Usine Process, stronger and smoother joint. After bending, the rim joint is arc welded. The welded seam is then milled for a smooth finish.

Black Shield Treatment

This treatment doubles the rim's lifespan against stone impacts and scratches. Super strong double coated treatment with a matt finish.

Infinity hub design

Efficient power transfer thanks to optimised non-contact spoke lacing (no noise under load) and tension distribution. The length of the spokes at the front and rear is identical. Maintenance is easy thanks to a tool-free solution.

QRM Auto Bearing Preload Technology

Qualite de Roulements Mavic Auto. Cartridge bearings double sealed with e3 internal clearance. Preload is automatically adjusted to guarantee a perfect spin with no play on the long run.

Technical Specifications:

• Profile depth: 25mm
• Inner width: 30mm
• Rear axle: 12x148mm *Front axle: 15x110mm
• Discipline: Downhill
• Spokes: Steel, Straight Pull, Flat
• Rim Diameter: 29"
• Nipples: Brass, Black
• Rim material: Maxtal
• Tyre compatibility: UST Tubeless Ready Use with Mavic Tubeless Tape
• Maximum weight: 135kg including bike
• Braking system: 6 Bolt
• Bearings: QRM automatic setting sealed cartridge
• ETRTO Size: 622x30TC
• Weight: 1980g

Intended Use

• Minimum tyre size: width 52mm - pressure max. 2.95Bar/43PSI
• Maximum tyre size: width 76mm - pressure max. 2.45Bar/36PSI
• ASTM category 4 : Enduro and trail riding
